HX100PKP Automatic Card Punching Machine Handles 700-1100 Sheets Per Hour

Name: HX100PKP Automatic Card Punching Machine Handles 700-1100 Sheets Per Hour
Brand: Dongguan Haoxin Precision Machinery Co., Ltd.
SKU: HX100PKP
Price: 191,475.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: HXCP

Certification: CE

Model Number: HX100PKP

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Packaging Details: Stretch Film with Wooden Case

Delivery Time: 30 work days

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 10 sets/month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                automatic card punching machine, card punching machine 700-1100 sheets per hour, card punching machine with warranty


Max Sheet Format:	1020×720mm(L×W)	Min Sheet Format:	550×450mm(L×W)
Punched Card Size:	Customized	Punching Pressure:	14-25T
Positioning Accuracy:	±0.05mm	Productivity:	700-1100sheetss/h
Applicable Card Materials:	Paper Card, PVC, ABS, PET, PVC/ABS Composite Materials, Etc.	Control:	PLC Control + Servo System + CCD
Drive:	Servo System	Operators:	1
Air Source:	0.6-0.8Mpa	Air Consumption:	150L/min
Power Supply:	3Phase AC 380V / 50/60HZ	Total Power:	10KW
Dimension:	3600×2050×1950mm(L×W×H)	Weight:	3300KG

Max Sheet Format:	1020×720mm(L×W)
Min Sheet Format:	550×450mm(L×W)
Punched Card Size:	Customized
Punching Pressure:	14-25T
Positioning Accuracy:	±0.05mm
Productivity:	700-1100sheetss/h
Applicable Card Materials:	Paper Card, PVC, ABS, PET, PVC/ABS Composite Materials, Etc.
Control:	PLC Control + Servo System + CCD
Drive:	Servo System
Operators:	1
Air Source:	0.6-0.8Mpa
Air Consumption:	150L/min
Power Supply:	3Phase AC 380V / 50/60HZ
Total Power:	10KW
Dimension:	3600×2050×1950mm(L×W×H)
Weight:	3300KG

Product Description

HX100PKP Automatic Paper Plastic Card Punching Machine

HX100PKP Automatic Card Punching Machine Handles 700-1100 Sheets Per Hour 1

Description:

HX100PKP Automatic Paper Plastic Card Punching Machine features an automatic sheet feeder coupled with vision system for reliable positioning. Punched cards are created in one step through processes of card forming, corner rounding, hole punching and creasing, and can be automatically collected in an orderly manner. The card punching system is suitable for manufacturing cards of various materials of Paper,PVC, ABS, PP,PC,PET, as well as PVC/ABS composite materials.

Features:

Product Name: HX100PKP Automatic Paper Plastic Card Punching Machine
Feeding System: Automatic sheet feeder for continuous production
Vision System: CCD vision system for reliable positioning and alignment
One-Step Process: Punched cards are created through card forming, corner rounding, hole punching, and creasing in one step
Card Collection: Automatically collects finished cards in an orderly manner
Material Compatibility: Suitable for Paper, PVC, ABS, PP, PC, PET, and PVC/ABS composite materials
Pressure Range: 14-25 tons punching force
Positioning Accuracy: ±0.05mm for high-precision results
Productivity: 700-1,100 sheets per hour
Control System: PLC Control + Servo System + CCD Vision
Operation: Requires only one operator

Keywords: Card Punching Machine, HX100PKP, Automatic Card Maker, Plastic Card Punch, Paper Card Punching, Vision System, CCD Positioning, Corner Rounding, Hole Punching, Card Creasing, PVC Card Punch, ABS Card Punch

Applications:

Card Manufacturing: Producing ID cards, membership cards, loyalty cards, gift cards, and access cards from various materials
Composite Card Production: Punching PVC/ABS composite cards for durable and high-quality card applications
Paper Card Products: Creating business cards, hang tags, promotional cards, and postcards with professional finishing
High-Precision Card Making: Ideal for manufacturers requiring ±0.05mm accuracy for card dimensions and hole positions
Medium to High-Volume Production: Processing 700-1,100 sheets per hour with automated feeding and collection
